GramLat® 3D Lattice™

The unique and attractive GramLat® 3D Lattice™ is the ONLY genuine double-sided, 3 Dimensional Prepainted Steel Lattice that was introduced into the market in 1999.

GramLat® 3D Lattice™ slats are rollformed into an exclusive profile that is an Australian registered product of GramLine® (Registration No. 141018S). The GramLine® brand is embossed on the lattice for peace of mind and traceability.

The GramLat® 3D Lattice™ is the perfect decorative addition option available as a complete system with your new fence or as an extension that can be added to your existing fence. It is a stylish and durable way to add privacy and security while also allowing the light and breeze to filter through.

Features & Benefits

  • Stylish & durable way to add privacy & security.
  • Matches the appearance of traditional lattice but has the advantage of being pre-painted, low maintenance and termite resistant.
  • Available in all the GramLine® Steel Fencing colour range.
  • Unique designs gives you the opportunity to purchase single or dual colour slats to complement the style and colour scheme of any home.
  • Comes in a variety standard heights and widths.
  • Made from Quality Tested and Certified Prepainted Hi-Tensile ColorSealed® coated steel.


GramLat® 3D Lattice™


Common heights on top of a Steel Privacy Fence are 300mm, 450mm or 600mm. Anything over 300mm high please refer to the GramLine® sales team.

A Gramline® Steel Lattice Extension Kit Consists of:

  • 1x 300mm x 2355mm GramLat™ 3D Lattice™
  • 2 x Rails 2370mm (horizontal)
  • 2 x 300mm Extension Posts
  • 18 x Self Drilling Screws

For other steel lattice applications the GramLat® 3D Lattice™ is available from 300mm high to 1200mm high in 150mm increments with three standard lengths; 2355mm, 2715mm, 3076mm. We can also cut to the desired length required
GramLat® 3D Lattice™ size chart

Material Specifications

  • GramLat® 3D Lattice™ are made from Quality Tested and Certified Prepainted Hi-Tensile ColorSealed® coated steel.
  • Slats are 40mm wide x 12.5mm thick which are clenched together to fit neatly into our rails.
  • Diagonal spacing between the slats is 45mm, 28% visibility.
  • The cut edges are fully protected from the weather to give this product the same life expectancy as the steel privacy fence you erect it on.

Product Specification

Please download our GramLine® Installation Guide.

GramLat® 3D Lattice™


GramLat® 3D Lattice™

GramLine® allows you to make more of a statement by adding either the Double Fence Caps or the Decorative Aluminium Balls. GramLat® 3D Lattice™ can also be installed on existing GramLine® Steel Privacy Fence using our Post Extensions.
